• high voltage laboratory power supply, compact bench case
• output voltage up to 30.000 Volt
• output current up to 500 mA
• residual ripple < 0,1% pp
• stability < 0,1% over 8h
• setting of output voltage with ten-turn potentiometer
• setting of output current with ten-turn potentiometer
• 3.5-digit digital displays for voltage and current, analogue displays on request
• analog interface
• external digital interface avalible as option
• sustained short-circuit resistant
|
Références
|
Tension de sortie
|
Courant
|
Performance
|
|
LNC 100-200
|
100 V
|
200 mA
|
20 W
|
|
LNC 100-500
|
100 V
|
500 mA
|
50 W
|
|
LNC 300 -100
|
300 V
|
100 mA
|
30 W
|
|
LNC 300-200
|
300 V
|
200 mA
|
60 W
|
|
LNC 600-50
|
600 V
|
50 mA
|
30 W
|
|
LNC 600-100
|
600 V
|
100 mA
|
60 W
|
|
LNC 1200-20
|
1200 V
|
20 mA
|
24 W
|
|
LNC 1200-50
|
1200 V
|
50 mA
|
60 W
|
|
LNC 3000-10
|
3000 V
|
10 mA
|
30 W
|
|
LNC 3000-20
|
3000 V
|
20 mA
|
60 W
|
|
LNC 6000 -5
|
6000 V
|
5 mA
|
30 W
|
|
LNC 6000 -15
|
6000 V
|
15 mA
|
60 W
|
|
LNC 10 000-2
|
10 000 V
|
2 mA
|
20 W
|
|
LNC 10 000-5
|
10 000 V
|
5 mA
|
50 W
|
|
LNC 20 000-3
|
20 000 V
|
3 mA
|
60 W
|
|
LNC 30 000-2
|
30 000 V
|
2 mA
|
60 W
|
|
