Alimentations AC/DC, de 1 W à 1000 W, Enclosed, Din-Rail, Open Frame et Encapsulated disponibles sous 2 à 4 semaines


Contactez-nous pour trouver votre équivalence produit

Mornsun est un des leaders mondiaux d'alimentations industrielles et propose plus de 6000 modèles d'alimentations standards, équivalents à de nombreux modèles existants. Mornsun est spécialisé dans les convertisseurs AC/DC & DC/DC

Mornsun propose ici des alimentations AC/DC de différents types, de 1 W à 1000 W:

  • Encapsulées / Encapsulated
  • Alimentation électrique capotée / Enclosed
  • Open-frame / Boitier ouvert
  • Din-Rail / Rail-Din / Montée sur rail

AC/DC Enclosed & Open Frame : MORNSUN vous propose une large gamme d’alimentations intégrables disponibles sous 2 à 4 semaines

AC/DC Rail DIN : MORNSUN vous propose une large gamme d’alimentations montage rail DIN disponibles sous 2 à 4 semaines

AC/DC Encapsulated : MORNSUN vous propose une large gamme d’alimentations encapsulés à piquer sur PCB disponibles sous 2 à 4 semaines

Avec plusieurs dizaines de références de 1 W a 1000 W, ces alimentations sont particulièrement adaptées pour les bornes de recharges de véhicules électriques.

Ces alimentations offrent d'excellentes performances en matière de CEM et répondent aux normes IEC/EN61000-4, CISPR32/EN55032, IEC/UL/EN62368, EN60335, EN60601, normes GB4943.

Conscients des contraintes pour cette application, les produits Mornsun répondent aux exigences suivantes :

  • Compatible avec la tension du réseau principal mondial :
    • Le chargeur EV est destiné au marché mondial, il sera donc compatible avec toutes les tensions de réseau.
  • Large tension d'entrée :
    • La tension du réseau n'est pas aussi stable que prévu, avec l'effet des harmoniques multiples, le réseau électrique sera en grande fluctuation.
    • En outre, le démarrage et l'arrêt de grands équipements électriques entraîneront également des fluctuations de tension.
  • Températures étendues : ( -30 °C - +70 °C ) :
    • En hiver, la température extérieure peut être aussi basse que - 30 ℃, ce qui peut entraîner un mauvais démarrage ou un fonctionnement anormal de l'alimentation électrique.
    • Fonctionnement anormal de l'alimentation électrique, ce qui rend la borne de charge incapable de fonctionner normalement.
  • Bonnes performances CEM :
    • La CEM comprend l'EMI et l'EMS.
      • EMI : Interférence électromagnétique, désigne l'interférence d'un équipement électronique avec son environnement.
      • EMS : Susceptibilité électromagnétique, la capacité d'éviter une pénalité de performance en cas de perturbation électromagnétique.
  • Haute efficacité :
    • Un chargeur EV certifié ENERGY STAR consomme 40% d'énergie en moins qu'un chargeur EV standard en mode veille.
    • Une alimentation à haut rendement peut aider le chargeur à obtenir la certification.
  • Test de fiabilité :
    • La fiabilité est l'une des considérations clés du chargeur de VE, le chargeur nécessite toutes sortes de tests de fiabilité.
    • Les chargeurs sont amenés à être utilisés dans des environnements humides
    • L'option de tropicalisation des alimentations Mornsun permet d'évoluer sereinement dans ce milieu

Références et spécifications :

Product Line Series Mornsun Part No. Certification Power (W) Input (VAC) Output (VDC) Qty/carton
AC-DC Enclosed LM15-23Bxx LM15-23B03 IEC/UL62368-1, GB4943.1 Safety Approval
& EN62368-1 (Report)		 9,9 85-305 3,3 120
LM15-23B05 15 85-305 5 120
LM15-23B12 15,6 85-305 12 120
LM15-23B15 15 85-305 15 120
LM15-23B24 15 85-305 24 120
LM15-23B48 15,36 85-305 48 120
AC-DC Enclosed LM25-23Bxx LM25-23B03 IEC/EN/UL62368/GB4943 19,8 85-305 3,3 85
LM25-23B05 25 85-305 5 85
LM25-23B12 25,2 85-305 12 85
LM25-23B15 25,5 85-305 15 85
LM25-23B24 26,4 85-305 24 85
LM25-23B48 27,36 85-305 48 85
AC-DC Enclosed LM35-20Bxx LM35-20B05 IEC/EN/UL62368/IEC/EN60335/GB4943/IEC/EN61558 35 85-264 5 52
LM35-20B12 36 85-264 12 52
LM35-20B15 36 85-264 15 52
LM35-20B24 36 85-264 24 52
AC-DC Enclosed LM35-20Bxx LM35-20B05 IEC/EN/UL62368/IEC/EN60335/GB4943/IEC/EN61558 35 85-264 5 52
LM35-20B12 36 85-264 12 52
LM35-20B15 36 85-264 15 52
LM35-20B24 36 85-264 24 52
AC-DC Enclosed LM35-10Dxx LM35-10D0512-10 IEC/EN/UL62368,EN60335,GB4943 32 85-264 5,12 52
LM35-10D0524-10 35 85-264 5,24 52
AC-DC Enclosed LM50-20Bxx LM50-20B05 IEC/EN/UL62368/IEC/EN60335/GB4943/IEC/EN61558 50 85-264 5 52
LM50-20B12 50,4 85-264 12 52
LM50-20B15 51 85-264 15 52
LM50-20B24 52,8 85-264 24 52
LM50-20B36 52,2 85-264 36 52
LM50-20B48 52,8 85-264 48 52
AC-DC Enclosed LM50-20Bxx LM50-20B05 IEC/EN/UL62368/IEC/EN60335/GB4943/IEC/EN61558 50 85-264 5 52
LM50-20B12 50,4 85-264 12 52
LM50-20B15 51 85-264 15 52
LM50-20B24 52,8 85-264 24 52
LM50-20B36 52,2 85-264 36 52
LM50-20B48 52,8 85-264 48 52
AC-DC Enclosed LM50-10Dxx LM50-10D0512-20 IEC/EN/UL62368,EN60335 54 85-264 5,12 52
LM50-10D0524-14 53,6 85-264 5,24 52
AC-DC Enclosed LM50-10Dxx LM50-10D0512-20 IEC/EN/UL62368,EN60335 54 85-264 5,12 52
LM50-10D0524-14 53,6 85-264 5,24 52
AC-DC Enclosed LM50-10Cxx LM50-10C051212-20 IEC/EN/UL62368,EN60335 50 85-264 5,±12 52
LM50-10C051515-15 50 85-264 5,±15 52
LM50-10C052412-10 51 85-264 5,+12,+24 52
AC-DC Enclosed LM75-20Bxx LM75-20B05 IEC/EN/UL62368/EN60335/EN61558/GB4943 70 85-264 5 48
LM75-20B12 72 85-264 12 48
LM75-20B15 75 85-264 15 48
LM75-20B24 76,8 85-264 24 48
LM75-20B36 75,6 85-264 36 48
LM75-20B48 76,8 85-264 48 48
AC-DC Enclosed LM75-20Bxx LM75-20B05 IEC/EN/UL62368/EN60335/EN61558/GB4943 70 85-264 5 48
LM75-20B12 72 85-264 12 48
LM75-20B15 75 85-264 15 48
LM75-20B24 76,8 85-264 24 48
LM75-20B36 75,6 85-264 36 48
LM75-20B48 76,8 85-264 48 48
AC-DC Enclosed LM75-10Dxx LM75-10D0512-30 EC/EN/UL62368,EN60335,GB4943 71 90-264 5,12 48
LM75-10D0524-20 73 90-264 5,24 48
AC-DC Enclosed LM75-10Dxx LM75-10D0512-30 EC/EN/UL62368,EN60335,GB4943 71 90-264 5,12 48
LM75-10D0524-20 73 90-264 5,24 48
AC-DC Enclosed LM75-10Cxx LM75-10C051212-28 EN62368 (approved)
Meet IEC/UL62368, EN60335, GB4943		 69,6 90-264 5,±12 48
LM75-10C051515-23 72 90-264 5,±15 48
LM75-10C052412-15 73 90-264 5,+12,+24 48
AC-DC Enclosed LM100-20Bxx LM100-20B05 IEC/EN/UL62368/EN60335/GB4943/EN61558 90 85-264 5 36
LM100-20B12 102 85-264 12 36
LM100-20B15 105 85-264 15 36
LM100-20B24 108 85-264 24 36
LM100-20B36 100,8 85-264 36 36
LM100-20B48 110,4 85-264 48 36
AC-DC Enclosed LM100-20Bxx LM100-20B05 IEC/EN/UL62368/EN60335/GB4943/EN61558 90 85-264 5 36
LM100-20B12 102 85-264 12 36
LM100-20B15 105 85-264 15 36
LM100-20B24 108 85-264 24 36
LM100-20B36 100,8 85-264 36 36
LM100-20B48 110,4 85-264 48 36
AC-DC Enclosed LM150-20Bxx LM150-20B12 IEC/EN/UL62368/EN60335/EN61558/GB4943 150 85-264 12 28
LM150-20B15 150 85-264 15 28
LM150-20B24 156 85-264 24 28
LM150-20B36 154,8 85-264 36 28
LM150-20B48 158,4 85-264 48 28
AC-DC Enclosed LM150-20Bxx LM150-20B12 IEC/EN/UL62368/EN60335/EN61558/GB4943 150 85-264 12 28
LM150-20B15 150 85-264 15 28
LM150-20B24 156 85-264 24 28
LM150-20B36 154,8 85-264 36 28
LM150-20B48 158,4 85-264 48 28
AC-DC Enclosed LM150-20Bxx LM150-20B12 IEC/EN/UL62368/EN60335/EN61558/GB4943 150 85-264 12 28
LM150-20B15 150 85-264 15 28
LM150-20B24 156 85-264 24 28
LM150-20B36 154,8 85-264 36 28
LM150-20B48 158,4 85-264 48 28
AC-DC Enclosed LM200-10Bxx LM200-10B05 UL/EN/IEC62368/GB4943 150 90-132 / 180-264 5 26
LM200-10B12 204 90-132 / 180-264 12 26
LM200-10B15 210 90-132 / 180-264 15 26
LM200-10B24 211,2 90-132 / 180-264 24 26
LM200-10B36 212,4 90-132 / 180-264 36 26
LM200-10B48 211,2 90-132 / 180-264 48 26
AC-DC Enclosed LM350-10Bxx LM350-10B05 IEC/EN/UL62368-1, GB4943.1 Safety
Approval & EN60950-1, EN62368-1
(Report)
Design refer to IEC/EN/UL62368-1, GB4943.1, EN60950-1, EN60335-1		 300 90-132 / 180-264 5 19
LM350-10B12 348 90-132 / 180-264 12 19
LM350-10B15 348 90-132 / 180-264 15 19
LM350-10B24 350,4 90-132 / 180-264 24 19
LM350-10B36 349,2 90-132 / 180-264 36 19
LM350-10B48 350,4 90-132 / 180-264 48 19
AC-DC Enclosed LM450-12Bxx LM450-12B12 EN62368
Meet UL/EN/IEC62368/GB4943		 450 176-264 / 240-373 12 19
LM450-12B15 450 176-264 / 240-373 15 19
LM450-12B24 451,2 176-264 / 240-373 24 19
LM450-12B27 450,9 176-264 / 240-373 27 19
LM450-12B36 450 176-264 / 240-373 36 19
LM450-12B48 451,2 176-264 / 240-373 48 19
AC-DC Enclosed LM600-12Bxx LM600-12B12 GB4943.1 Safety Approval & EN62368-1
(Report)
Design refer to IEC/EN/UL62368-1, GB4943.1		 600 176-264 / 240-373 12 8
LM600-12B15 600 176-264 / 240-373 15 8
LM600-12B24 600 176-264 / 240-373 24 8
LM600-12B27 599,4 176-264 / 240-373 27 8
LM600-12B36 597,6 176-264 / 240-373 36 8
LM600-12B48 600 176-264 / 240-373 48 8
AC-DC Enclosed LMF75-20Bxx
(with PFC)		 LMF75-20B05 IEC/EN62368/EN60335/EN61558/GB4943 75 85-264 5 28
LMF75-20B12 75,6 85-264 12 28
LMF75-20B15 75 85-264 15 28
LMF75-20B24 76,8 85-264 24 28
LMF75-20B48 76,8 85-264 48 28
AC-DC Enclosed LMF75-20Bxx
(with PFC)		 LMF75-20B05 IEC/EN62368/EN60335/EN61558/GB4943 75 85-264 5 28
LMF75-20B12 75,6 85-264 12 28
LMF75-20B15 75 85-264 15 28
LMF75-20B24 76,8 85-264 24 28
LMF75-20B48 76,8 85-264 48 28
AC-DC Enclosed LMF100-23Bxx
(with PFC)		 LMF100-23B12 IEC/EN/UL62368, GB4943 102 85-305 12 26
LMF100-23B15 100,5 85-305 15 26
LMF100-23B24 100,8 85-305 24 26
LMF100-23B48 100,8 85-305 48 26
AC-DC Enclosed LMF100-23Bxx
(with PFC)		 LMF100-23B12 IEC/EN/UL62368, GB4943 102 85-305 12 26
LMF100-23B15 100,5 85-305 15 26
LMF100-23B24 100,8 85-305 24 26
LMF100-23B48 100,8 85-305 48 26
AC-DC Enclosed LMF150-23Bxx
(with PFC)		 LMF150-23B12 UL/EN/IEC62368/GB4943
Meet UL/EN/IEC62368/EN60335/EN61558/GB4943		 150 85-305 12 26
LMF150-23B15 150 85-305 15 26
LMF150-23B24 151,2 85-305 24 26
LMF150-23B48 153,6 85-305 48 26
AC-DC Enclosed LMF150-23Bxx
(with PFC)		 LMF150-23B12 UL/EN/IEC62368/GB4943
Meet UL/EN/IEC62368/EN60335/EN61558/GB4943		 150 85-305 12 26
LMF150-23B15 150 85-305 15 26
LMF150-23B24 151,2 85-305 24 26
LMF150-23B48 153,6 85-305 48 26
AC-DC Enclosed LMF150-23Bxx
(with PFC)		 LMF150-23B12 UL/EN/IEC62368/GB4943
Meet UL/EN/IEC62368/EN60335/EN61558/GB4943		 150 85-305 12 26
LMF150-23B15 150 85-305 15 26
LMF150-23B24 151,2 85-305 24 26
LMF150-23B48 153,6 85-305 48 26
AC-DC Enclosed LMF200-23Bxx
(with PFC)		 LMF200-23B05 UL62368-1, GB4943.1 safety approved &
EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1, GB4943.1		 200 85-305 5 19
LMF200-23B12 200,4 85-305 12 26
LMF200-23B15 201 85-305 15 26
LMF200-23B24 201,6 85-305 24 26
LMF200-23B48 201,6 85-305 48 26
AC-DC Enclosed LMF200-23Bxx
(with PFC)		 LMF200-23B05 UL62368-1, GB4943.1 safety approved &
EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1, GB4943.1		 200 85-305 5 19
LMF200-23B12 200,4 85-305 12 26
LMF200-23B15 201 85-305 15 26
LMF200-23B24 201,6 85-305 24 26
LMF200-23B48 201,6 85-305 48 26
AC-DC Enclosed LMF200-23Bxx
(with PFC)		 LMF200-23B05 UL62368-1, GB4943.1 safety approved &
EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1, GB4943.1		 200 85-305 5 19
LMF200-23B12 200,4 85-305 12 26
LMF200-23B15 201 85-305 15 26
LMF200-23B24 201,6 85-305 24 26
LMF200-23B48 201,6 85-305 48 26
AC-DC Enclosed LMF200-23Bxx
(with PFC)		 LMF200-23B05 UL62368-1, GB4943.1 safety approved &
EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1, GB4943.1		 200 85-305 5 19
LMF200-23B12 200,4 85-305 12 26
LMF200-23B15 201 85-305 15 26
LMF200-23B24 201,6 85-305 24 26
LMF200-23B48 201,6 85-305 48 26
AC-DC Enclosed LMF320-23Bxx
(with PFC)		 LMF320-23B05 IEC/UL62368-1, GB4943.1 safety approved &
EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, GB4943.1,
IEC60950-1, EN60335-1		 300 85-305 5 19
LMF320-23B12 320,4 85-305 12 19
LMF320-23B15 321 85-305 15 19
LMF320-23B24 321,6 85-305 24 19
LMF320-23B48 321,6 85-305 48 19
AC-DC Enclosed LMF320-23Bxx
(with PFC)		 LMF320-23B05 IEC/UL62368-1, GB4943.1 safety approved &
EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, GB4943.1,
IEC60950-1, EN60335-1		 300 85-305 5 19
LMF320-23B12 320,4 85-305 12 19
LMF320-23B15 321 85-305 15 19
LMF320-23B24 321,6 85-305 24 19
LMF320-23B48 321,6 85-305 48 19
AC-DC Enclosed LMF320-23Bxx
(with PFC)		 LMF320-23B05 IEC/UL62368-1, GB4943.1 safety approved &
EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, GB4943.1,
IEC60950-1, EN60335-1		 300 85-305 5 19
LMF320-23B12 320,4 85-305 12 19
LMF320-23B15 321 85-305 15 19
LMF320-23B24 321,6 85-305 24 19
LMF320-23B48 321,6 85-305 48 19
AC-DC Enclosed LMF600-20Bxx
(with PFC)		 LMF600-20B12 EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, EN61558-2-16, EN61558-1, EN60335-1, IEC/EN60601-1, GB4943.1		 600 85-264 12 18
LMF600-20B24 600 85-264 24 18
LMF600-20B36 600 85-264 36 18
LMF600-20B48 600 85-264 48 18
AC-DC Enclosed LMF600-20Bxx
(with PFC)		 LMF600-20B12 EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, EN61558-2-16, EN61558-1, EN60335-1, IEC/EN60601-1, GB4943.1		 600 85-264 12 18
LMF600-20B24 600 85-264 24 18
LMF600-20B36 600 85-264 36 18
LMF600-20B48 600 85-264 48 18
AC-DC Enclosed LMF600-20Bxx
(with PFC)		 LMF600-20B12 EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, EN61558-2-16, EN61558-1, EN60335-1, IEC/EN60601-1, GB4943.1		 600 85-264 12 18
LMF600-20B24 600 85-264 24 18
LMF600-20B36 600 85-264 36 18
LMF600-20B48 600 85-264 48 18
AC-DC Enclosed LMF600-20Bxx
(with PFC)		 LMF600-20B12 EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, EN61558-2-16, EN61558-1, EN60335-1, IEC/EN60601-1, GB4943.1		 600 85-264 12 18
LMF600-20B24 600 85-264 24 18
LMF600-20B36 600 85-264 36 18
LMF600-20B48 600 85-264 48 18
AC-DC Enclosed LMF1000-20Bxx
(with PFC)		 LMF1000-20B12 Design refer to IEC/UL/EN62368-1
IEC/ES/EN60601-1-2:2015 Edition 4		 960 90-264 12 14
LMF1000-20B24 1008 90-264 24 14
LMF1000-20B48 1008 90-264 48 14
AC-DC Enclosed LMF1000-20Bxx
(with PFC)		 LMF1000-20B12 Design refer to IEC/UL/EN62368-1
IEC/ES/EN60601-1-2:2015 Edition 4		 960 90-264 12 14
LMF1000-20B24 1008 90-264 24 14
LMF1000-20B48 1008 90-264 48 14
AC-DC Enclosed LMF1000-20Bxx
(with PFC)		 LMF1000-20B12 Design refer to IEC/UL/EN62368-1
IEC/ES/EN60601-1-2:2015 Edition 4		 960 90-264 12 14
LMF1000-20B24 1008 90-264 24 14
LMF1000-20B48 1008 90-264 48 14
AC-DC Enclosed LM65-10J051224-MT LM65-10J051224-MT DesignrefertoIEC/EN/UL62368-1 65 88-264 68 36
AC-DC Din-Rail LI15-20BxxPR2 LI15-20B05PR2 Design refer to UL/IEC62368-1/EN62368-1
IEC/EN61010-1
IEC/EN61558-1
IEC60335-1
EN62368-1 (Report) Safety Approval		 12 85-264 5 /
LI15-20B12PR2 15 85-264 12 /
LI15-20B15PR2 15 85-264 15 /
LI15-20B24PR2 15,2 85-264 24 /
LI15-20B48PR2 15,4 85-264 48 /
AC-DC Din-Rail LI15-20BxxPR2 LI15-20B05PR2 Design refer to UL/IEC62368-1/EN62368-1
IEC/EN61010-1
IEC/EN61558-1
IEC60335-1
EN62368-1 (Report) Safety Approval		 12 85-264 5 /
LI15-20B12PR2 15 85-264 12 /
LI15-20B15PR2 15 85-264 15 /
LI15-20B24PR2 15,2 85-264 24 /
LI15-20B48PR2 15,4 85-264 48 /
AC-DC Din-Rail LI30-20BxxPR2 LI30-20B05PR2 UL62368-1/IEC62368-1 Safety Approval
EN62368-1 (Report)
Design refer to EN61558-1		 30 85-264 5 54
LI30-20B12PR2 30 85-264 12 54
LI30-20B15PR2 30 85-264 15 54
LI30-20B24PR2 30 85-264 24 54
LI30-20B48PR2 30 85-264 48 54
AC-DC Din-Rail LI30-20BxxPR2 LI30-20B05PR2 UL62368-1/IEC62368-1 Safety Approval
EN62368-1 (Report)
Design refer to EN61558-1		 30 85-264 5 54
LI30-20B12PR2 30 85-264 12 54
LI30-20B15PR2 30 85-264 15 54
LI30-20B24PR2 30 85-264 24 54
LI30-20B48PR2 30 85-264 48 54
AC-DC Din-Rail LI60-20BxxPR2 LI60-20B05PR2 UL62368-1/IEC62368-1 Safety Approval
EN62368-1 (Report)
Design refer to EN61558-1		 60 85-264 5 36
LI60-20B12PR2 60 85-264 12 36
LI60-20B15PR2 60 85-264 15 36
LI60-20B24PR2 60 85-264 24 36
LI60-20B48PR2 60 85-264 48 36
AC-DC Din-Rail LI75-20BxxR2 LI75-20B12R2 EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, GB4943.1,
IEC/EN60335-1, UL508		 75 85-264 12 /
LI75-20B24R2 75 85-264 24 /
LI75-20B48R2 75 85-264 48 /
AC-DC Din-Rail LI75-20BxxR2 LI75-20B12R2 EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, GB4943.1,
IEC/EN60335-1, UL508		 75 85-264 12 /
LI75-20B24R2 75 85-264 24 /
LI75-20B48R2 75 85-264 48 /
AC-DC Din-Rail LI75-20BxxR2 LI75-20B12R2 EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, GB4943.1,
IEC/EN60335-1, UL508		 75 85-264 12 /
LI75-20B24R2 75 85-264 24 /
LI75-20B48R2 75 85-264 48 /
AC-DC Din-Rail LI75-20BxxR2S LI75-20B12R2S EN62368-1 (Report)
Design refer to UL61010-1, EN62368-1		 75,6 85-264 12 28
LI75-20B24R2S 76,8 85-264 24 28
LI75-20B48R2S 76,8 85-264 48 28
AC-DC Din-Rail LI75-20BxxR2S LI75-20B12R2S EN62368-1 (Report)
Design refer to UL61010-1, EN62368-1		 75,6 85-264 12 28
LI75-20B24R2S 76,8 85-264 24 28
LI75-20B48R2S 76,8 85-264 48 28
AC-DC Din-Rail LI75-20BxxR2S LI75-20B12R2S EN62368-1 (Report)
Design refer to UL61010-1, EN62368-1		 75,6 85-264 12 28
LI75-20B24R2S 76,8 85-264 24 28
LI75-20B48R2S 76,8 85-264 48 28
AC-DC Din-Rail LI100-20BxxPR2 LI100-20B12PR2 UL62368-1/IEC62368-1 Safety Approval
EN62368-1 (Report)
Design refer to EN61558-1		 100 85-264 12 24
LI100-20B15PR2 100 85-264 15 24
LI100-20B24PR2 100 85-264 24 24
LI100-20B48PR2 100 85-264 48 24
AC-DC Din-Rail LI150-20BxxPR2 LI150-20B12PR2 UL/EN/IEC62368, EN/IEC60335, IEC61558, UL61010 135,6 85-264 12 27
LI150-20B15PR3 142,5 85-264 15 27
LI150-20B24PR4 150 85-264 24 27
LI150-20B48PR5 153,6 85-264 48 27
AC-DC Din-Rail LI120-20BxxR2S LI120-20B12R2S EN62368-1
Meet UL61010-1/UL508/EN62368-1		 120 90-264 12 18
LI120-20B24R2S 120 90-264 24 18
LI120-20B48R2S 120 90-264 48 18
AC-DC Din-Rail LI120-20BxxR2S LI120-20B12R2S EN62368-1
Meet UL61010-1/UL508/EN62368-1		 120 90-264 12 18
LI120-20B24R2S 120 90-264 24 18
LI120-20B48R2S 120 90-264 48 18
AC-DC Din-Rail LIF120-10BxxR2
(with PFC)		 LIF120-10B12R2 UL61010-1, UL61010-2-201 safety approved &
EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, UL61010-1, UL61010-2-201		 120 85-264 12 18
LIF120-10B24R2 120 85-264 24 18
LIF120-10B48R2 120 85-264 48 18
AC-DC Din-Rail LIF240-10BxxR2
(with PFC)		 LIF240-10B12R2 LIF120-10BxxR2
Meet IEC/EN/UL62368/UL61010		 192 85-264 12 18
LIF240-10B24R2 240 85-264 24 18
LIF240-10B48R2 240 85-264 48 18
AC-DC Din-Rail LIF240-10BxxR2
(with PFC)		 LIF240-10B12R2 LIF120-10BxxR2
Meet IEC/EN/UL62368/UL61010		 192 85-264 12 18
LIF240-10B24R2 240 85-264 24 18
LIF240-10B48R2 240 85-264 48 18
AC-DC Din-Rail LIF480-10BxxR2
(with PFC)		 LIF480-10B24R2 Design refer to IEC/EN/UL62368-1, UL61010-1, UL508 480 85-264 24 12
LIF480-10B48R2 480 85-264 48 12
AC-DC Din-Rail LIF480-10BxxR2
(with PFC)		 LIF480-10B24R2 Design refer to IEC/EN/UL62368-1, UL61010-1, UL508 480 85-264 24 12
LIF480-10B48R2 480 85-264 48 12
AC-DC Din-Rail KNX20 KNX20-22A640 Meet EN61558-2-16/IEC63044-3:2018, EN62368
safety approved		 19,2 180-264 30 36
AC-DC Open-frame LO15-10Bxx
2.5"×1.8"		 LO15-10B03 UL/EN/IEC62368 9 85-264 3,3 120
LO15-10B05 14 85-264 5 120
LO15-10B09 15 85-264 9 120
LO15-10B12 15 85-264 12 120
LO15-10B15 15 85-264 15 120
LO15-10B24 15 85-264 24 120
AC-DC Open-frame LO30-10Bxx
3"×2"		 LO30-10B03 UL/EN/IEC62368 13,5 85-264 3,3 108
LO30-10B05 20,5 85-264 5 108
LO30-10B09 30 85-264 9 108
LO30-10B12 30 85-264 12 108
LO30-10B15 30 85-264 15 108
LO30-10B24 30 85-264 24 108
LO30-10B48 30 85-264 48 108
AC-DC Open-frame LO30-10Bxx
3"×2"		 LO30-10B03 UL/EN/IEC62368 13,5 85-264 3,3 108
LO30-10B05 20,5 85-264 5 108
LO30-10B09 30 85-264 9 108
LO30-10B12 30 85-264 12 108
LO30-10B15 30 85-264 15 108
LO30-10B24 30 85-264 24 108
LO30-10B48 30 85-264 48 108
AC-DC Open-frame LO45-10Bxx
3"×2"		 LO45-10B03 UL/EN/IEC62368 26,4 85-264 3,3 108
LO45-10B05 40 85-264 5 108
LO45-10B09 40 85-264 9 108
LO45-10B12 45 85-264 12 108
LO45-10B15 45 85-264 15 108
LO45-10B24 45 85-264 24 108
LO45-10B48 45 85-264 48 108
AC-DC Open-frame LO65-10Bxx
3"×2"		 LO65-10B05 UL/IEC62368-1 & EN62368-1 (Report) 50 85-264 5 108
LO65-10B09 60 85-264 9 108
LO65-10B12 65 85-264 12 108
LO65-10B15 65 85-264 15 108
LO65-10B24 65 85-264 24 108
LO65-10B48 65 85-264 48 108
AC-DC Open-frame LO45-20BxxMU
3"×2"		 LO45-20B03MU EN62368-1 (Report)
Design refer to IEC/EN60601-1
ES60601-1 (3.1 version)
CAN/CSA 22.2 No.60601-1:14-Edition 3
EN60601-1-2 Edition 4
UL/IEC62368-1
EN60335-1
EN61558-1
GB4943.1		 26,4 85-264 3,3 108
LO45-20B05MU 40 85-264 5 108
LO45-20B12MU 45 85-264 12 108
LO45-20B15MU 45 85-264 15 108
LO45-20B24MU 45 85-264 24 108
LO45-20B30MU 45 85-264 30 108
LO45-20B36MU 45 85-264 36 108
LO45-20B48MU 45 85-264 48 108
AC-DC Open-frame LO45-20BxxMU
3"×2"		 LO45-20B03MU EN62368-1 (Report)
Design refer to IEC/EN60601-1
ES60601-1 (3.1 version)
CAN/CSA 22.2 No.60601-1:14-Edition 3
EN60601-1-2 Edition 4
UL/IEC62368-1
EN60335-1
EN61558-1
GB4943.1		 26,4 85-264 3,3 108
LO45-20B05MU 40 85-264 5 108
LO45-20B12MU 45 85-264 12 108
LO45-20B15MU 45 85-264 15 108
LO45-20B24MU 45 85-264 24 108
LO45-20B30MU 45 85-264 30 108
LO45-20B36MU 45 85-264 36 108
LO45-20B48MU 45 85-264 48 108
AC-DC Open-frame LO65-20BxxMU
3"×2"		 LO65-20B03MU EN62368-1 (Report)
Design refer to IEC/EN60601-1
ES60601-1 (3.1 version)
CAN/CSA-C22.2 No.60601-1:14-Edition 3
EN60601-1-2 Edition 4
UL/IEC62368-1
EN60335-1
EN61558-1
GB4943.1		 33 85-264 3,3 108
LO65-20B05MU 50 85-264 5 108
LO65-20B12MU 65 85-264 12 108
LO65-20B15MU 65 85-264 15 108
LO65-20B24MU 65 85-264 24 108
LO65-20B36MU 65 85-264 36 108
LO65-20B48MU 65 85-264 48 108
AC-DC Open-frame LO65-20BxxMU
3"×2"		 LO65-20B03MU EN62368-1 (Report)
Design refer to IEC/EN60601-1
ES60601-1 (3.1 version)
CAN/CSA-C22.2 No.60601-1:14-Edition 3
EN60601-1-2 Edition 4
UL/IEC62368-1
EN60335-1
EN61558-1
GB4943.1		 33 85-264 3,3 108
LO65-20B05MU 50 85-264 5 108
LO65-20B12MU 65 85-264 12 108
LO65-20B15MU 65 85-264 15 108
LO65-20B24MU 65 85-264 24 108
LO65-20B36MU 65 85-264 36 108
LO65-20B48MU 65 85-264 48 108
AC-DC Open-frame LO65-20BxxMU
3"×2"		 LO65-20B03MU EN62368-1 (Report)
Design refer to IEC/EN60601-1
ES60601-1 (3.1 version)
CAN/CSA-C22.2 No.60601-1:14-Edition 3
EN60601-1-2 Edition 4
UL/IEC62368-1
EN60335-1
EN61558-1
GB4943.1		 33 85-264 3,3 108
LO65-20B05MU 50 85-264 5 108
LO65-20B12MU 65 85-264 12 108
LO65-20B15MU 65 85-264 15 108
LO65-20B24MU 65 85-264 24 108
LO65-20B36MU 65 85-264 36 108
LO65-20B48MU 65 85-264 48 108
AC-DC Open-frame LOF120-20Bxx
(with PFC)
3"×2"		 LOF120-20B12 IEC/UL62368-1, ES60601-1 safety approved &
EN62368-1, EN60335-1, EN61558-1, EN60601-1
(Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1 version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 114 85-264 12 72
LOF120-20B15 114 85-264 15 72
LOF120-20B24 120 85-264 24 72
LOF120-20B27 119,9 85-264 27 72
LOF120-20B36 120 85-264 36 72
LOF120-20B48 120 85-264 48 72
LOF120-20B54 120 85-264 54 72
AC-DC Open-frame LOF120-20Bxx
(with PFC)
3"×2"		 LOF120-20B12 IEC/UL62368-1, ES60601-1 safety approved &
EN62368-1, EN60335-1, EN61558-1, EN60601-1
(Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1 version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 114 85-264 12 72
LOF120-20B15 114 85-264 15 72
LOF120-20B24 120 85-264 24 72
LOF120-20B27 119,9 85-264 27 72
LOF120-20B36 120 85-264 36 72
LOF120-20B48 120 85-264 48 72
LOF120-20B54 120 85-264 54 72
AC-DC Open-frame LOF120-20Bxx
(with PFC)
3"×2"		 LOF120-20B12 IEC/UL62368-1, ES60601-1 safety approved &
EN62368-1, EN60335-1, EN61558-1, EN60601-1
(Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1 version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 114 85-264 12 72
LOF120-20B15 114 85-264 15 72
LOF120-20B24 120 85-264 24 72
LOF120-20B27 119,9 85-264 27 72
LOF120-20B36 120 85-264 36 72
LOF120-20B48 120 85-264 48 72
LOF120-20B54 120 85-264 54 72
AC-DC Open-frame LOF120-20Bxx
(with PFC)
3"×2"		 LOF120-20B12 IEC/UL62368-1, ES60601-1 safety approved &
EN62368-1, EN60335-1, EN61558-1, EN60601-1
(Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1 version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 114 85-264 12 72
LOF120-20B15 114 85-264 15 72
LOF120-20B24 120 85-264 24 72
LOF120-20B27 119,9 85-264 27 72
LOF120-20B36 120 85-264 36 72
LOF120-20B48 120 85-264 48 72
LOF120-20B54 120 85-264 54 72
AC-DC Open-frame LOF120-20Bxx
(with PFC)
3"×2"		 LOF120-20B12 12V/15V/24V/27V/48V: IEC/EN/UL62368-1/EN60335/IEC61558/UL/EN60601
(UL/EN60601 pending)
36V: UL/EN60601 (pending)
54V: EN62368 (pending)		 114 85-264 12 72
LOF120-20B15 114 85-264 15 72
LOF120-20B24 120 85-264 24 72
LOF120-20B27 119,9 85-264 27 72
LOF120-20B36 120 85-264 36 72
LOF120-20B48 120 85-264 48 72
LOF120-20B54 120 85-264 54 72
AC-DC Open-frame LOF225-20Bxx
(with PFC)
4"×2"		 LOF225-20B12 IEC/UL62368-1, ES60601-1, IEC60335-1 safety
approved & EN62368-1, EN60335-1, EN61558-1, EN60601-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1 version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 225 85-264 12 72
LOF225-20B15 225 85-264 15 72
LOF225-20B24 225 85-264 24 72
LOF225-20B27 225 85-264 27 72
LOF225-20B36 225 85-264 36 72
LOF225-20B48 225 85-264 48 72
LOF225-20B54 225 85-264 54 72
AC-DC Open-frame LOF225-20Bxx
(with PFC)
4"×2"		 LOF225-20B12 IEC/UL62368-1, ES60601-1, IEC60335-1 safety
approved & EN62368-1, EN60335-1, EN61558-1, EN60601-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1 version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 225 85-264 12 72
LOF225-20B15 225 85-264 15 72
LOF225-20B24 225 85-264 24 72
LOF225-20B27 225 85-264 27 72
LOF225-20B36 225 85-264 36 72
LOF225-20B48 225 85-264 48 72
LOF225-20B54 225 85-264 54 72
AC-DC Open-frame LOF225-20Bxx
(with PFC)
4"×2"		 LOF225-20B12 IEC/UL62368-1, ES60601-1, IEC60335-1 safety
approved & EN62368-1, EN60335-1, EN61558-1, EN60601-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1 version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 225 85-264 12 72
LOF225-20B15 225 85-264 15 72
LOF225-20B24 225 85-264 24 72
LOF225-20B27 225 85-264 27 72
LOF225-20B36 225 85-264 36 72
LOF225-20B48 225 85-264 48 72
LOF225-20B54 225 85-264 54 72
AC-DC Open-frame LOF350-20Bxx
(with PFC)
5"×3"		 LOF350-20B12 IEC/UL62368-1, ES60601-1 safety qpproved &
EN60335-1, EN61558-1, EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943-1, IEC/EN60601-1, ES60601-1(3.1version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 300 90-264 12 42
LOF350-20B15 325 90-264 15 42
LOF350-20B24 350,4 90-264 24 42
LOF350-20B27 351 90-264 27 42
LOF350-20B36 350,28 90-264 36 42
LOF350-20B48 350,4 90-264 48 42
LOF350-20B54 351 90-264 54 42
AC-DC Open-frame LOF350-20Bxx
(with PFC)
5"×3"		 LOF350-20B12 IEC/UL62368-1, ES60601-1 safety qpproved &
EN60335-1, EN61558-1, EN62368-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943-1, IEC/EN60601-1, ES60601-1(3.1version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 300 90-264 12 42
LOF350-20B15 325 90-264 15 42
LOF350-20B24 350,4 90-264 24 42
LOF350-20B27 351 90-264 27 42
LOF350-20B36 350,28 90-264 36 42
LOF350-20B48 350,4 90-264 48 42
LOF350-20B54 351 90-264 54 42
AC-DC Enclosed LOF120-20Bxx-C
(with PFC)		 LOF120-20B12-C IEC/UL62368-1, ES60601-1 safety approved &
EN60335-1, EN61558-1, EN60601-1, EN62368-1
(Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 114 85-264 12 54
LOF120-20B15-C 114 85-264 15 54
LOF120-20B24-C 120 85-264 24 54
LOF120-20B27-C 119,9 85-264 27 54
LOF120-20B36-C 120 85-264 36 54
LOF120-20B48-C 120 85-264 48 54
LOF120-20B54-C 120 85-264 54 54
AC-DC Enclosed LOF120-20Bxx-C
(with PFC)		 LOF120-20B12-C IEC/UL62368-1, ES60601-1 safety approved &
EN60335-1, EN61558-1, EN60601-1, EN62368-1
(Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 114 85-264 12 54
LOF120-20B15-C 114 85-264 15 54
LOF120-20B24-C 120 85-264 24 54
LOF120-20B27-C 119,9 85-264 27 54
LOF120-20B36-C 120 85-264 36 54
LOF120-20B48-C 120 85-264 48 54
LOF120-20B54-C 120 85-264 54 54
AC-DC Enclosed LOF225-20Bxx-C
(with PFC)		 LOF225-20B12-C IEC/UL62368-1, ES60601-1 safety approved &
EN60335-1, EN61558-1, EN60601-1, EN62368-1
(Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1 version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 225 85-264 12 51
LOF225-20B15-C 225 85-264 15 51
LOF225-20B24-C 225 85-264 24 51
LOF225-20B27-C 225 85-264 27 51
LOF225-20B36-C 225 85-264 36 51
LOF225-20B48-C 225 85-264 48 51
LOF225-20B54-C 225 85-264 54 51
AC-DC Enclosed LOF225-20Bxx-C
(with PFC)		 LOF225-20B12-C IEC/UL62368-1, ES60601-1 safety approved &
EN60335-1, EN61558-1, EN60601-1, EN62368-1
(Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943.1, IEC/EN60601-1, ES60601-1(3.1 version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 225 85-264 12 51
LOF225-20B15-C 225 85-264 15 51
LOF225-20B24-C 225 85-264 24 51
LOF225-20B27-C 225 85-264 27 51
LOF225-20B36-C 225 85-264 36 51
LOF225-20B48-C 225 85-264 48 51
LOF225-20B54-C 225 85-264 54 51
AC-DC Enclosed LOF350-20Bxx-C
(with PFC)		 LOF350-20B12-C IEC/EN/UL62368-1, ES60601-1 , EN60335-1 &
EN61558-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943-1, IEC/EN60601-1, ES60601-1(3.1version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 300 90-264 12 30
LOF350-20B15-C 325 90-264 15 30
LOF350-20B24-C 350,4 90-264 24 30
LOF350-20B27-C 351 90-264 27 30
LOF350-20B36-C 350,28 90-264 36 30
LOF350-20B48-C 350,4 90-264 48 30
LOF350-20B54-C 351 90-264 54 30
AC-DC Enclosed LOF350-20Bxx-C
(with PFC)		 LOF350-20B12-C IEC/EN/UL62368-1, ES60601-1 , EN60335-1 &
EN61558-1 (Report)
Design refer to IEC/EN/UL62368-1, EN60335-1,
IEC/EN61558-1, GB4943-1, IEC/EN60601-1, ES60601-1(3.1version), CAN/CSA-C22.2
No.60601-1:14-Edition 3, EN60601-1-2 Edition 4		 300 90-264 12 30
LOF350-20B15-C 325 90-264 15 30
LOF350-20B24-C 350,4 90-264 24 30
LOF350-20B27-C 351 90-264 27 30
LOF350-20B36-C 350,28 90-264 36 30
LOF350-20B48-C 350,4 90-264 48 30
LOF350-20B54-C 351 90-264 54 30
AC-DC Open-frame LOF450-20Bxx
(with PFC)
5"×3"		 LOF450-20B12 EN62368-1, EN/ES60601-1 Safety Approval
& EN62368-1 (Report);
Design refer to
IEC 62368-1, GB4943.1, EN60335-1		 400 90-264 12 24
LOF450-20B15 400 90-264 15 24
LOF450-20B24 450 90-264 24 24
LOF450-20B27 450 90-264 27 24
LOF450-20B36 450 90-264 36 24
LOF450-20B48 450 90-264 48 24
AC-DC Open-frame LOF450-20Bxx
(with PFC)
5"×3"		 LOF450-20B12 EN62368-1, EN/ES60601-1 Safety Approval
& EN62368-1 (Report);
Design refer to
IEC 62368-1, GB4943.1, EN60335-1		 400 90-264 12 24
LOF450-20B15 400 90-264 15 24
LOF450-20B24 450 90-264 24 24
LOF450-20B27 450 90-264 27 24
LOF450-20B36 450 90-264 36 24
LOF450-20B48 450 90-264 48 24
AC-DC Enclosed LOF450-20Bxx-C
(with PFC)		 LOF450-20B12-C EN62368-1, EN/ES60601-1 Safety Approval
& EN62368-1 (Report);
Design refer to
IEC 62368-1, GB4943.1, EN60335-1		 399,6 90-264 12 30
LOF450-20B15-C 400,5 90-264 15 30
LOF450-20B24-C 450 90-264 24 30
LOF450-20B27-C 450,9 90-264 27 30
LOF450-20B36-C 450 90-264 36 30
LOF450-20B48-C 451,2 90-264 48 30
AC-DC Enclosed LOF450-20Bxx-C
(with PFC)		 LOF450-20B12-C EN62368-1, EN/ES60601-1 Safety Approval
& EN62368-1 (Report);
Design refer to
IEC 62368-1, GB4943.1, EN60335-1		 399,6 90-264 12 30
LOF450-20B15-C 400,5 90-264 15 30
LOF450-20B24-C 450 90-264 24 30
LOF450-20B27-C 450,9 90-264 27 30
LOF450-20B36-C 450 90-264 36 30
LOF450-20B48-C 451,2 90-264 48 30
AC-DC Open-frame LOF550-20Bxx
(with PFC)
5"×3"		 LOF550-20B12 EN62368-1, EN/ES60601-1 Safety Approval &
EN62368-1 (Report);
Design refer to
IEC/UL/ 62368-1, GB4943.1, EN60335-1		 499,2 90-264 12 24
LOF550-20B15 499,5 90-264 15 24
LOF550-20B24 549,6 90-264 24 24
LOF550-20B27 550,8 90-264 27 24
LOF550-20B36 550,8 90-264 36 24
LOF550-20B48 550 90-264 48 24
AC-DC Open-frame LOF550-20Bxx
(with PFC)
5"×3"		 LOF550-20B12 EN62368-1, EN/ES60601-1 Safety Approval &
EN62368-1 (Report);
Design refer to
IEC/UL/ 62368-1, GB4943.1, EN60335-1		 499,2 90-264 12 24
LOF550-20B15 499,5 90-264 15 24
LOF550-20B24 549,6 90-264 24 24
LOF550-20B27 550,8 90-264 27 24
LOF550-20B36 550,8 90-264 36 24
LOF550-20B48 550 90-264 48 24
AC-DC Enclosed LOF550-20Bxx-C
(with PFC)		 LOF550-20B12-C EN62368-1, EN/ES60601-1 Safety Approval &
EN62368-1 (Report);
Design refer to
IEC/UL/ 62368-1, GB4943.1, EN60335-1		 499,2 90-264 12 24
LOF550-20B15-C 499,5 90-264 15 24
LOF550-20B24-C 549,6 90-264 24 24
LOF550-20B27-C 550,8 90-264 27 24
LOF550-20B36-C 550,8 90-264 36 24
LOF550-20B48-C 550 90-264 48 24
AC-DC Encapsulated LD01-10Bxx LD01-10B03 EN60950/UL60950 1 85-305 3,3 704
LD01-10B05 1 85-305 5 704
LD01-10B09 1 85-305 9 704
LD01-10B12 1 85-305 12 704
LD01-10B15 1 85-305 15 704
LD01-10B24 1 85-305 24 704
AC-DC Encapsulated LDE02-23Bxx LDE02-23B03 IEC62368/EN62368/UL62368 2 85-305 3,3 704
LDE02-23B05 2 85-305 5 704
LDE02-23B09 2 85-305 9 704
LDE02-23B12 2 85-305 12 704
LDE02-23B15 2 85-305 15 704
LDE02-23B24 2 85-305 24 704
AC-DC Encapsulated LDE03-20Bxx LDE03-20B03 EC62368/EN62368/UL62368 2,3 85-264 3 360
LDE03-20B05 3 85-264 5 360
LDE03-20B09 3 85-264 9 360
LDE03-20B12 3 85-264 12 360
LDE03-20B15 3 85-264 15 360
LDE03-20B24 3 85-264 24 360
AC-DC Encapsulated LD05-23BxxR2-M LD05-23B03R2-M EN62368 4,95 85-305 3,3 210
LD05-23B05R2-M 5 85-305 5 210
LD05-23B09R2-M 5,04 85-305 9 210
LD05-23B12R2-M 5,04 85-305 12 210
LD05-23B15R2-M 4,95 85-305 15 210
LD05-23B24R2-M 5,52 85-305 24 210
AC-DC Encapsulated LD05-23BxxR2-M LD05-23B03R2-M EN62368 4,95 85-305 3,3 210
LD05-23B05R2-M 5 85-305 5 210
LD05-23B09R2-M 5,04 85-305 9 210
LD05-23B12R2-M 5,04 85-305 12 210
LD05-23B15R2-M 4,95 85-305 15 210
LD05-23B24R2-M 5,52 85-305 24 210
AC-DC Encapsulated LD05-23BxxR2-M LD05-23B03R2-M EN62368 4,95 85-305 3,3 210
LD05-23B05R2-M 5 85-305 5 210
LD05-23B09R2-M 5,04 85-305 9 210
LD05-23B12R2-M 5,04 85-305 12 210
LD05-23B15R2-M 4,95 85-305 15 210
LD05-23B24R2-M 5,52 85-305 24 210
AC-DC Encapsulated LD10-23BxxR2-M LD10-23B03R2-M IEC/EN/UL62368/EN60335/EN61558 10 85-305 3,3 210
LD10-23B05R2-M 10 85-305 5 210
LD10-23B09R2-M 10 85-305 9 210
LD10-23B12R2-M 10 85-305 12 210
LD10-23B15R2-M 10 85-305 15 210
LD10-23B24R2-M 10 85-305 24 210
AC-DC Encapsulated LD10-23BxxR2-M LD10-23B03R2-M IEC/EN/UL62368/EN60335/EN61558 10 85-305 3,3 210
LD10-23B05R2-M 10 85-305 5 210
LD10-23B09R2-M 10 85-305 9 210
LD10-23B12R2-M 10 85-305 12 210
LD10-23B15R2-M 10 85-305 15 210
LD10-23B24R2-M 10 85-305 24 210
AC-DC Encapsulated LD10-23BxxR2-M LD10-23B03R2-M IEC/EN/UL62368/EN60335/EN61558 10 85-305 3,3 210
LD10-23B05R2-M 10 85-305 5 210
LD10-23B09R2-M 10 85-305 9 210
LD10-23B12R2-M 10 85-305 12 210
LD10-23B15R2-M 10 85-305 15 210
LD10-23B24R2-M 10 85-305 24 210
AC-DC Encapsulated LD15-23BxxR2-M LD15-23B03R2-M UL/EN/IEC62368/EN60335/EN61558 13,2 85-305 3,3 210
LD15-23B05R2-M 15 85-305 5 210
LD15-23B09R2-M 15 85-305 9 210
LD15-23B12R2-M 15 85-305 12 210
LD15-23B15R2-M 15 85-305 15 210
LD15-23B24R2-M 15 85-305 24 210
AC-DC Encapsulated LD15-23BxxR2-M LD15-23B03R2-M UL/EN/IEC62368/EN60335/EN61558 13,2 85-305 3,3 210
LD15-23B05R2-M 15 85-305 5 210
LD15-23B09R2-M 15 85-305 9 210
LD15-23B12R2-M 15 85-305 12 210
LD15-23B15R2-M 15 85-305 15 210
LD15-23B24R2-M 15 85-305 24 210
AC-DC Encapsulated LD15-23BxxR2-M LD15-23B03R2-M UL/EN/IEC62368/EN60335/EN61558 13,2 85-305 3,3 210
LD15-23B05R2-M 15 85-305 5 210
LD15-23B09R2-M 15 85-305 9 210
LD15-23B12R2-M 15 85-305 12 210
LD15-23B15R2-M 15 85-305 15 210
LD15-23B24R2-M 15 85-305 24 210
AC-DC Encapsulated LD20-23BxxR2 LD20-23B03R2 IEC/UL62368-1, EN61558-1, EN60335-1 Safety
Approval & EN62368-1 (Report);
Design refer to IEC/EN60601-1/ANSI/AAMI
ES60601-1		 14,85 85-305 3,3 210
LD20-23B05R2 20 85-305 5 210
LD20-23B09R2 20 85-305 9 210
LD20-23B12R2 20 85-305 12 210
LD20-23B15R2 20 85-305 15 210
LD20-23B24R2 20 85-305 24 210
AC-DC Encapsulated LD20-23BxxR2 LD20-23B03R2 IEC/UL62368-1, EN61558-1, EN60335-1 Safety
Approval & EN62368-1 (Report);
Design refer to IEC/EN60601-1/ANSI/AAMI
ES60601-1		 14,85 85-305 3,3 210
LD20-23B05R2 20 85-305 5 210
LD20-23B09R2 20 85-305 9 210
LD20-23B12R2 20 85-305 12 210
LD20-23B15R2 20 85-305 15 210
LD20-23B24R2 20 85-305 24 210
AC-DC Encapsulated LD20-23BxxR2 LD20-23B03R2 IEC/UL62368-1, EN61558-1, EN60335-1 Safety
Approval & EN62368-1 (Report);
Design refer to IEC/EN60601-1/ANSI/AAMI
ES60601-1		 14,85 85-305 3,3 210
LD20-23B05R2 20 85-305 5 210
LD20-23B09R2 20 85-305 9 210
LD20-23B12R2 20 85-305 12 210
LD20-23B15R2 20 85-305 15 210
LD20-23B24R2 20 85-305 24 210
AC-DC Encapsulated LD30-23BxxR2 LD30-23B03R2 IEC/UL62368-1, EN61558-1, EN60335-1 Safety
Approval & EN62368-1 (Report)		 19,8 85-305 3,3 120
LD30-23B05R2 30 85-305 5 120
LD30-23B09R2 30,6 85-305 9 120
LD30-23B12R2 30 85-305 12 120
LD30-23B15R2 30 85-305 15 120
LD30-23B24R2 31,2 85-305 24 120
LD30-23B48R2 30,2 85-305 48 120
AC-DC Encapsulated LD30-23BxxR2 LD30-23B03R2 IEC/UL62368-1, EN61558-1, EN60335-1 Safety
Approval & EN62368-1 (Report)		 19,8 85-305 3,3 120
LD30-23B05R2 30 85-305 5 120
LD30-23B09R2 30,6 85-305 9 120
LD30-23B12R2 30 85-305 12 120
LD30-23B15R2 30 85-305 15 120
LD30-23B24R2 31,2 85-305 24 120
LD30-23B48R2 30,2 85-305 48 120
AC-DC Encapsulated LD30-23BxxR2A2S LD30-23B03R2A2S IEC/UL62368-1, EN61558-1, EN60335-1 Safety
Approval & EN62368-1 (Report)		 19,8 85-305 3,3 120
LD30-23B05R2A2S 30 85-305 5 120
LD30-23B09R2A2S 30,6 85-305 9 120
LD30-23B12R2A2S 30 85-305 12 120
LD30-23B15R2A2S 30 85-305 15 120
LD30-23B24R2A2S 31,2 85-305 24 120
LD30-23B48R2A2S 30,2 85-305 48 120
AC-DC Encapsulated LDE45-20Bxx LDE45-20B05 IEC62368/EN62368/UL62368 40 85-305 5 60
LDE45-20B12 45 85-305 12 60
LDE45-20B15 45 85-305 15 60
LDE45-20B24 45 85-305 24 60
LDE45-20B48 45 85-305 48 60
AC-DC Encapsulated LDE45-20Bxx LDE45-20B05 IEC62368/EN62368/UL62368 40 85-305 5 60
LDE45-20B12 45 85-305 12 60
LDE45-20B15 45 85-305 15 60
LDE45-20B24 45 85-305 24 60
LDE45-20B48 45 85-305 48 60
AC-DC Encapsulated LDE45-20BxxA2S LDE45-20B05A2S IEC62368/EN62368/UL62368 40 85-305 5 60
LDE45-20B12A2S 45 85-305 12 60
LDE45-20B15A2S 45 85-305 15 60
LDE45-20B24A2S 45 85-305 24 60
LDE45-20B48A2S 45 85-305 48 60
AC-DC Encapsulated LDE45-20BxxA2S LDE45-20B05A2S IEC62368/EN62368/UL62368 40 85-305 5 60
LDE45-20B12A2S 45 85-305 12 60
LDE45-20B15A2S 45 85-305 15 60
LDE45-20B24A2S 45 85-305 24 60
LDE45-20B48A2S 45 85-305 48 60
AC-DC Encapsulated LDE60-20Bxx LDE60-20B05 IEC/UL62368-1 Safety Approval & EN62368-1
(Report)		 50 85-305 5 60
LDE60-20B12 60 85-305 12 60
LDE60-20B15 60 85-305 15 60
LDE60-20B24 60 85-305 24 60
LDE60-20B48 60 85-305 48 60
AC-DC Encapsulated LDE60-20Bxx LDE60-20B05 IEC/UL62368-1 Safety Approval & EN62368-1
(Report)		 50 85-305 5 60
LDE60-20B12 60 85-305 12 60
LDE60-20B15 60 85-305 15 60
LDE60-20B24 60 85-305 24 60
LDE60-20B48 60 85-305 48 60
AC-DC Encapsulated LDE60-20BxxA2S LDE60-20B05A2S IEC/UL62368-1 Safety Approval & EN62368-1
(Report)		 50 85-305 5 60
LDE60-20B12A2S 60 85-305 12 60
LDE60-20B15A2S 60 85-305 15 60
LDE60-20B24A2S 60 85-305 24 60
LDE60-20B48A2S 60 85-305 48 60
AC-DC Encapsulated LDE60-20BxxA2S LDE60-20B05A2S IEC/UL62368-1 Safety Approval & EN62368-1
(Report)		 50 85-305 5 60
LDE60-20B12A2S 60 85-305 12 60
LDE60-20B15A2S 60 85-305 15 60
LDE60-20B24A2S 60 85-305 24 60
LDE60-20B48A2S 60 85-305 48 60

Close
