Description
Specifications :
Screen Size : 21.3cm (8.4 inch) Number of Pixels : 800 x 600 Pixel Pitch (H, V/mm) : 0.1665 × 0.1665 Brightness : 500cd/m2 Contrast Ratio : 600:1 Electrical Interface : LVDS Power Supply Voltage : 3.3V Viewing Angle (°) : 80/80 (R/L) 80/60 (U/D)* Number of Colors : 262k/16.77M (6-bit/8-bit) Module Size (W x H x D) : 199.5 × 149.0 × 11.5mm Module Mass : 370g (typ) Backlight Unit : LED, Edge-light replaceable Optimum Viewing Angle(Contrast Ratio) : 6 o'clock*
* By Reverse Scanning direction, the direction of the viewing angle can be changed to suit Optimum Viewing Angle.
