Téléchargez le guide de sélection des microphones GRAS
Le microphone basse fréquence est un instrument de mesure hautement spécialisé conçu pour capturer avec précision les sons et vibrations à très basse fréquence. Ce dispositif est particulièrement adapté pour les mesures infra-sonores et les applications nécessitant une grande sensibilité dans les basses fréquences.
Specifications | 46AN | 46AZ | 47AC |
---|---|---|---|
Size | 12.7 (½") mm (housing) | 12.7 (½") mm (housing) | 12.7 (½") mm (housing) |
Application | Free field | Free field | Free field |
Sensitivity | 50 mV/pa | 50 mV/pa | 8 mV/pa |
Dynamic Range | 17 dB(A) – 149 dB re 20 µPa | 17 dB(A) – 138 dB re 20 µPa | 20 dB(A) – 148 dB re 20 µPa |
Frequency Range | 0.5 Hz – 20 kHz | 0.5 Hz – 20 kHz | 0.09 Hz – 20 kHz |
Polarization voltage | 200 V | 0 V | 0 V |
IEC 61094 designation | WS2F | WS2F | WS2F |
